GVWR/GCWR
|
12,000 lbs. |
PAYLOAD (preliminary) | 12ft. @ 3,408 lbs./14ft. @ 3,267 lbs. |
GAWR front | 5,360 lbs. |
GAWR rear | 8,840 lbs. |
Front Axle Capacity | 6,830 lbs. |
Rear Axle Capacity | 11,020 lbs. |
Ratio | 5.125 |
Suspension | |
F/R Springs | Tapered/Multi-Leaf |
Capacity | 6,830/9,880 lbs. |
Frame | |
Section Modulus | 6.07 in.³ |
Resistance Bending Moment | 267,080 lb.-ft./in. |
Service Brakes | |
System | Vacuum/Hydraulic with 4-Channel ABS |
Front/Rear | Disc/Drum |
Transmission | |
Standard | Aisin A460 6-speed auto. with double overdrive and lock-up 2nd-6th gears |
Engine | Isuzu 4JJ1-TC turbocharged intercooled diesel |
Displacement | 3.0L (183 in.³) |
Engine Power | 150hp @ 2,800 rpm |
Engine Torque | 282 lb.-ft. @ 1,600-2,800 rpm |
Oil Level Indicator | Dash-mounted oil level check switch and light |
Limited Slip Differential | Optional |
Alternator | 140-amp |
Batteries | 2 Maintenance-free 750-CCA |
Tires | 215/85R16E (10-ply) |
Steering / Steering Column | Integral hydraulic power / Tilt column |
Fuel Tank | 25 Gallon in-rail / 33 Gal. 176 WB only |
Fuel/Water Separator | Dual fuel filter with dash-mounted indicator light |
Standard on the NPR ECO-MAX is the newest engine in the Isuzu family -- the 4JJ1-TC.
Its high-pressure common-rail fuel injection system wrings the most energy out of every drop of fuel, and its intercooled, variable-geometry turbocharger provides excellent response over the engine's entire RPM range. Together, these features help the 4JJ1-TC produce 150 horsepower and 282 lbs.-ft. of torque.
Despite its spirited performance, this engine is a miser. In fact, the NPR ECO-MAX achieves up to 20% better fuel economy than the previous 12,000-lb. GVWR NPR. Like every Isuzu powerplant, the 4JJ1-TC is a true commercial vehicle engine. Each component has been crafted to reduce maintenance and increase durability.
So it's no surprise that the 4JJ1-TC can be driven up to 10,000 miles between oil changes and has a class-leading B10 durability rating of 310,000 miles -- meaning that 90% of 4JJ1-TC engines will reach that mileage before requiring an overhaul.
Its high-pressure common-rail fuel injection system wrings the most energy out of every drop of fuel, and its intercooled, variable-geometry turbocharger provides excellent response over the engine's entire RPM range. Together, these features help the 4JJ1-TC produce 150 horsepower and 282 lbs.-ft. of torque.
Despite its spirited performance, this engine is a miser. In fact, the NPR ECO-MAX achieves up to 20% better fuel economy than the previous 12,000-lb. GVWR NPR. Like every Isuzu powerplant, the 4JJ1-TC is a true commercial vehicle engine. Each component has been crafted to reduce maintenance and increase durability.
So it's no surprise that the 4JJ1-TC can be driven up to 10,000 miles between oil changes and has a class-leading B10 durability rating of 310,000 miles -- meaning that 90% of 4JJ1-TC engines will reach that mileage before requiring an overhaul.
![n-series-dimensions](/media/dealer_186/storage/images/details/midd/reach-van_dimension.jpg)
Reach body dimension
Dimension | Description | 12' | 14' |
A | Cargo Floor Length | 150.9" | 171.0 |
B | Behind Rear Axle | 69.8" | 89.9" |
C | Overall Length | 260.9" | 281.0" |
D | Wheel Base | 151.0" | 151.0" |
E | Bulkhead to Axle | 94.6" | 94.6" |
